Tricone Bits | |||
Size | IADC Code | API Thread | |
inch | mm | ||
3 7/8'' | 98.4 | 126/216/637 | 2 3/8 |
4 7/8'' | 117.4 | 126/216/517/537/637 | 2 7/8 |
5 1/4'' | 133.3 | 126/216/517/537/637 | 3 1/2 |
5 5/8'' | 142.8 | 126/216/517/537/637 | 3 1/2 |
5 7/8'' | 149.2 | 126/216/517/537/637 | 3 1/2 |
6'' | 152.4 | 126/127/216/517/537/617/637 | 3 1/2 |
6 1/4'' | 158.7 | 126/127/216/517/537/617/637 | 3 1/2 |
6 1/2'' | 165 | 126/127/216/517/537/617/637 | 3 1/2 |
7 1/2'' | 190 | 126/216/517/537 | 4 1/2 |
7 5/8'' | 193 | 126/216/517/537 | 4 1/2 |
7 7/8'' | 200 | 126/216/517/537 | 4 1/2 |
8 1/2'' | 215.9 | 117/127/217/437/517/537/617/637 | 4 1/2 |
9 1/2'' | 241.3 | 117/127/217/437/517/537/617/637 | 6 5/8 |
9 7/8'' | 250.8 | 117/127/217/437/517/537/617/637 | 6 5/8 |
10 5/8'' | 269.8 | 117/127/217/437/517/537/617/637 | 6 5/8 |
11 5/8'' | 295.3 | 117/127/217/437/517/537/617/637 | 6 5/8 |
12 1/4'' | 311.1 | 117/127/217/437/517/537/617/637 | 6 5/8 |
13 5/8'' | 346 | 127/217/517/537/617/637 | 6 5/8 |
14 3/4'' | 374.6 | 127/217/517/537/617/637 | 7 5/8 |
17 1/2'' | 444.5 | 114/115/125/215/515/535/615/635 | 7 5/8 |
26'' | 660.4 | 114/115/125/215/515/535/615 | 7 5/8 |
The roller cone bit has the functions of impacting, crushing and shearing the formation rock when it rotates, so the roller cone bit can adapt to various soft, medium and hard formations.
The 8 1/2'' inch IADC437 roller cone bit is suitable for low compressive strength and high drillability of large sections of very soft ground, such as shale, clay, sandstone, conglomerate, etc.
Our TCI bit is engineered for exceptional performance in challenging drilling conditions, offering enhanced durability and drilling speed.
